KTV娱乐音箱

TS系列音箱

￭型号 Model:TS10

￭声学性能Acoustic design:10"Passive loudspeaker,2-way

￭配置Components:HF1×1.4"(44mm)driver,LF1×10"(65mm)

￭频率响应Frequenty range:50Hz-20KHz(-10dB)

￭额定功率Power rating (RMS/Peak 10ms):300W/1200W

￭灵敏度Sensitivity(1w at 1m):96dB

￭最大声压级Maximum SPL1m:121dB;125dB(Peak)

￭标称阻抗Nominal impedance:8Ω

￭覆盖角度Nominal dispersion angle(HxV): 90°×40°

￭连接器Connections:2×Speakon NL4

￭尺寸Dimensions (H×W×D):510mm×300mm×345mm

￭重量Weight:18Kg

￭型号 Model:TS12

￭声学性能Acoustic design:12"Passive loudspeaker,2-way

￭配置Components:HF1×1.4"(44mm)NEO driver, LF1×12"(75mm)

￭频率响应Frequenty range:50Hz-20KHz(-10dB)

￭额定功率Power rating (RMS/Peak 10ms):400W/1800W

￭灵敏度Sensitivity(1w at 1m):98dB

￭最大声压级Maximum SPL1m:123dB;128dB(Peak)

￭标称阻抗Nominal impedance:4Ω

￭覆盖角度Nominal dispersion angle(HxV): 90°×60°

￭连接器Connections:2×Speakon NL4

￭尺寸Dimensions (H×W×D):620mm×370mm×430mm

￭重量Weight:21.9Kg

￭应用领域 Applications：KTV包房，夜总会，俱乐部，音乐餐吧，小型家庭娱乐。
